Product Details:
Payment & Shipping Terms:
|
Screw Design: | Single/Double | Voltage: | 380V 50HZ 3Phase(Customized) |
---|---|---|---|
Screw Material: | Bimetallic | Feeder Material: | Stainless Steel 304 |
High Light: | single screw extruder machine,single screw extrusion machine |
Multi Function Single Screw Plastic Extruder For PVC PE Pipe | Sheet Making recycling
Main Technical parameter of single screw extruder:
Model | SJ-45-33 | SJ-60-33 | SJ-75-33 | SJ-90-33 | SJ-120-33 | SJ-150-33 |
SCREW DIAMETER | 45 | 60 | 75 | 90 | 120 | 150 |
SCREW L/D RATIO | 33 | 33 | 33 | 33 | 33 | 33 |
SCREW TORQUE | 1430 | 4300 | 7160 | 12900 | 25000 | 45200 |
EXTRUSION CAPACITY | 160-180 | 260-280 | 450-500 | 600-650 | 950-1000 | 1200-1300 |
PP PELLET(KG/H) | 120-140 | 180-200 | 320-370 | 420-470 | 700-750 | 900-1000 |
Product process:
Single Screw Small Plastic Extruder is mainly used for experiment, that used for testing and extruding thermo-plastic such as soft hard polyvinyl chloride (PVC) and polystyrene(PE), PP, ABS,PLA coordinated with the appropriate auxiliary machine.
This set is advanced in design, good in plasticization and low in energy consumption. The extruder is characterized by low noise, stable working, big bearing capacity and long service life.
PP PE PVC plastic pipe making extruder:
1. Suitable to U-PVC,C-PVC,M-PVC ,PE, PPR,PP,HDPE,LDPE pipe extrusion
2. Single screw plastic extruder with various diameter and wall thickness, from 16-800mm.
3. the plastic pipe production line mainly includes twin screw extruder, pipe extrusion die, vacuum calibrating water tank, spray cooling water tank, hauling unit, cutting unit and stack unit.the extruder is specially designed for producing variours pipe.
4.adoped the Simens, ABB, Schneider famous brand electric components and high quality extruder alloy screw and barrel
5. Supply technical service, formula guide and staple raw material purchase
Plastic pelletizing extruder
Many materials can be processed directly without need of the upstream pre-shredding,resulting in a dramatic reduction in operational costs.
Less power consumption cost per kilogram,high throughput,reduced floor space occupation and operator attendance.
Applicable plastic materials: PP, HDPE, LDPE,LLDPE,TPV,EVA,ABS and PS,etc
Material shapes: film,bag, flake
Material types: woven bag, printed LDPE film,film (rolls, loose,bundled),agricultural film waste,foamed plastics(EPS) and raffia.
Plastic drainage sheet extruder:
application:
1) Traffic Engineering: Roads, railway embankment and slope protection layer.
2) Landscape engineering
3) Construction : Building the basis of the upper or lower, basement and outside walls, roof waterproof and insulation .
4) Municipal engineering: Subway , tunnels , road embankment.
5) Garden Project: Soccer fields, golf courses, garage greening roof projects.
If you want to know more informations ,Welcome to contact with us!
Contact Person: Shadow Fan
Tel: 0086 139 1360 8802
