500kg/h Wet Films Squeezer Wasted Plastic Agriculture Dirty Film Washing Line


Large Image :  500kg/h Wet Films Squeezer Wasted Plastic Agriculture Dirty Film Washing Line

Product Details:
Place of Origin: JIANGSU,CHINA
Brand Name: STPLAS
Certification: CE SGS
Model Number: STPLAS 14
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: contact us
Packaging Details: film or plywood packing suit for shipping
Delivery Time: 30-45days
Payment Terms: Western Union, MoneyGram, D/A, L/C, D/P, T/T
Supply Ability: 20 sets/month
Detailed Product Description
Material: 304 Stainless Steel Screw: Single Screw
Cutter: With Cutter Final Products: Pellets
Warranty: 13month After-sales Service Provided: Engineers Available To Service Machinery Overseas
Certification: CE,ISO9001,SGS Application: Film Squeezing Machine
Condition: New Voltage: 380V 50 HZ 3P
Machine Name: Films Squeezer Plastic Film Squeezer: Plastic Film Washing Line


Wet Films Squeezer Wasted Plastic Agriculture Dirty Film Washing Line




It is a full automatic Squeezer & Pelletizing Machine to the film and woven bags, with the screw squeezing and electrical heating, make the materials have high degree of drying and full plasticizing, low power consumption, high output. The final moisture is only 3-5%. The capacity would be customized according to the requests of clients.



Features :


1) This machine is our new designed machine, made by the advanced Eur techniques, specially screw pressing design;
2) This squeezer machine is especially for plastic film, plastic bags, woven bags, jumbo bags, solve them drying problems.
3) Instead of the dewatering machine, hot blower in the recycling line and energy saving equipment.
4) Energy saving, power saving, easy to operation.



Technical Parameter:


Model STSQ-500
Capacity 500-600kg/h
Screw Diameter Φ320mm(38CRMOAL)
Rotary Speed 60rpm
Main Motor power 132KW
Heating Power 10KW
Cutting pellet motor 4KW
Pellets size 12-20mm
Fan Power 5.5KW
Storage Hopper 1m3(stainless steel)
Inlet size 550*290mm
Dimension 3500×2220×2300mm
Weight 5.5tons



More Photos:

500kg/h Wet Films Squeezer Wasted Plastic Agriculture Dirty Film Washing Line 0


The complete PE PP film bags crushing washing drying system we also supply:


Film washing line is widely used to treat PP/PE plastic waste mixed material into clean film flakes, which include waste PP woven bags, PP non-woven bags, LDPE film, plastic garbage, waste plastic mulch film. After films cleaned, you can make them to be granules with next process which is called pelletizing line. This production line is high automatic operating and save labor cost and low after maintenance. With advanced international industry concepts and technologies to meet waste plastic recycling at home or abroad. This PP PE recycling machine could be displayed "L" or "U" shape according clients' workshop.

Generally, for the complete PP/PE film washing machine, we have several types for your choosing. The capacity we can supply 300kg/h, 500kg/h and 1000kg/h, you can choose the suitable one what you real need.


1. LDPE waste film recycling and washing line
2. PE agriculture using films crushing and washing line
3. Waste PE film recycling line
4. Ethylene ground film washing, drying and regranulating line
5. Waste film recycling and washing line

Peformance presented:
1. Final output dimension: 40-60mm
2. Moisture content: 5-8%
3. Capacity: 300-800kg/h (Solution may vary depending on customer's specialized requirement)


Model STPEPP-300 STPEPP-500 STPEPP-1000 STPEPP-1500
Capacity (KG/H) 300 500 1000 1500
Water consumption(T/H) 2--3 3--4 4--5 5--7
Power Consumption(T/H) 130--160 210-260 300-350 400-460
Staff(person) 2-3 2-3 3-5 3-5
Factory Area (M2) 30*4*5 40*4*5 45*6*5 55*6*5


500kg/h Wet Films Squeezer Wasted Plastic Agriculture Dirty Film Washing Line 1




If you want to know more informations ,welcome to contact with us.
