Waste Fiber Plastic Shredder Machine With Siemens PLC Control 8-16mm

China Waste Fiber Plastic Shredder Machine With Siemens PLC Control 8-16mm supplier

Large Image :  Waste Fiber Plastic Shredder Machine With Siemens PLC Control 8-16mm

Product Details:

Place of Origin: JIANGSU,CHINA
Brand Name: STPLAS
Certification: CE
Model Number: ST1-800

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: contact us
Packaging Details: Plywood package suit for shipping.
Delivery Time: 30days-60days after received the deposit
Payment Terms: T/T
Supply Ability: 30 set/ month
Contact Now
Detailed Product Description
Motor Power: Plastic Shredder Machine Blade Material: SKD-II Or D-2
Shaft: Single /double Shredder Shaft Diameter: 400-480 Mm
Application: Recycled Industry Usage:: Rubber Shredding Waste Plastic Shredding
Material: Wood, PE, Metal, Cloth,tire,wood Pallet,pipe Mesh Diameter: 8-16mm

Waste Fiber Plastic Shredder Machine With Siemens PLC Control 8-16mm





Plastic Shredder Machine character



1, main shaft is driven by gear reducer, big torque, steady working and low noise.

2, hydraulic feeding mechanism, independent power unit, strong frame structure.

3, rotor blades can be rotated and used on four edges before replacement.

4, quick change screens for accurate particle size control.

5, shredding chamber floor with brass guides & nylon slides.

6, hydraulic system with air cooling or water cooling design.

7, electrical cabinet with Siemens PLC control system, auto control for co-rotation and reversal.

8, Auto protection while over-load.

9, with ECM CE certification.



1. Rotor shaft "V" shape design,Use SKD-11 and D-2 material,Fixed blade by screw,no welding. it will more easy for shredding and maintenance for worker
2. Use the top branded BONENG gear box

3. Use the vibration-proof system to reduce the gear box loading protect the gear box
4.Rotor Shaft Automatic Forward and reversal,control by Siemens PLC



Model ST-800 ST-1200
Capacity(T/hour) 0.8-2 2~4
Specification of feeding(mm) ≤800 ≤1200
Specification of discharging(mm) ≤50x50 ≤60x60
Main Motor(Kw) 37 45x2
Discharging Motor (Kw) 3 4
Cutter rotate speed(r/min) 16 10
Screener rotate speed 6 4


Plastic Shredder Machine Features:


1. With good shaft structure design, stable running, durable use.
2. PLC control system, overload protection, more safe to operate.
3. Blades are fixed on the shaft by screw, convenient and easy to change
4. Every rotary blades has four cutting edges, it can be rotated by 180 degree continue to use if is worn.
