PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery

PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery
PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery

Large Image :  PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery

Product Details:

Place of Origin: CHINA
Brand Name: STPLAS
Certification: CE
Model Number: bottle washing recycling line

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Contact Us
Packaging Details: film packing suit for shipping
Delivery Time: 30-80days
Payment Terms: T/T
Supply Ability: 10 lines/year
Detailed Product Description
Type: Multi-Layer Co-Extrusion Film Blowing Machine Capacity: >300kg Per Hour Or Customized
Process Material: PP/PE Film Final Film Size: 30-50 Mm
Power: 380V 50HZ Or Customized Dimension(L*W*H): 85M*7M*5.2M
Function:: Remove Oil, Impurities. Manpower: 3-5 Persons
High Light:

plastic bottle recycling machine

,

plastic bottle recycling equipment

PP PE Plastic Film Washing Line / PP Jumbo Woven Bag plastic recycling machinery

This line is specialized designed for recycling plastic film. (PP/PE film, agriculture film)

1. High automation level, try best to reduce your cost on labor (especially for three shifts) and ensure high processing capacity: 300_500kg/hr
2. Friendly control system (PLC integrated & separated control on each machine) and Touch screen panel, easy for operation, monitor and emergency stop.
3. All parts contacting with plastic material and water are made of high-quality 304 stainless steel; Ensure no second pollution to plastic.
4. Ideal impurity removal effect.



Raw Material-plastic recycling machinery
Waste Plastic, HDPE Bottles, PE/PP Film

Capacity Model-plastic recycling machinery
According to different plastic material

General Machine List Components-plastic recycling machinery

For PE/PP bottle,film and so on
Feeding Conveyor---Plastic Crusher machine---Flakes Floating washing tank---Frication washing system---dewatering machinery ---hot air drying system and the Packing system



Belt conveyor→Crusher → Double screw conveyor→High speed friction washer→Screw conveyor→Hot washer→Drainage screw→Screw conveyor→Vertical dewatering machine→Drying system→Zig zag air classify system→Storage hopper→Control cabinet

No Name Power
1 Belt conveyor 1.5kw
2 Crusher 37kw
3 Double screw conveyor 1.5kw *2
4 High speed friction washer machine 11kw
5 Screw conveyor 2kw
6 Floating washer 1.5kw+1.5kw+1.5kw
7 Drainage screw 1.5kw
8 Screw conveyor 1.5kw
9 Vertical dewatering machine 5.5kw
10 Drying system 36kw + 7.5kw
11 Zig zag air classify system 11kw +7.5kw


PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery 0

PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery 1

PP PE Plastic Film Washing Line / PP Jumbo Woven Bag Recycling Machinery 2
