Product Details:
Payment & Shipping Terms:
|
| Material: | 304SS With Water Part | Warranty Period: | One Year For Free,Lifelong Maintenance |
|---|---|---|---|
| Crusher Blade: | SKD-II Or D2 | Steam Usage: | Gas/Electric/Diesel |
| Floating Washer Tank: | Hot Washer/Cold Washer | Friction Washer: | High Speed With Special Screw |
| Dewatering: | Centrifugal New Design | Motor: | Siemens Or As Your Requirement |
| High Light: | pet recycling machine,pet plastic recycling machine |
||
PET Washing line for 90% label remover
and cap remover machine
1. Raw material: waste pet bottles
2. capacity: 500-3000kg/h according to client's demand
3. Function:use waste pet bottles to produce pet flakes, then also granulation.
4. It is special product for washing& crushing& recycling PET bottles, such as the mineral water bottles, oil bottles, etc.. We supply full set of machines which can make waste plastic bottles to flakes.
5. The clean flakes can be used to produce the polyester staple fiber, PET strap band, granules, PET transparent film and sheets, etc. The top class flakes can be used to blow bottles again.
Main Technical of Waste PET Bottle Plastic Washing Recycling Machine Line:
| Input capacity | 500kg/h | 1000 kg/h | 2000 kg/h |
| Workshop(M*M*M) | 42 (L)×10(W)×6(H) | 55(L)×15(W)×6(H) | 70(L)×18(W)×6(H) |
| Ancillary staff | 6Persons | 8 Persons | 12 Persons |
| Installation power | 156KW | 307KW | 420KW |
| Water Consumption: | 2Ton/h | 3.5Ton/h | 5 Ton/h |
| Final product | Moisture: max 1% | ||
Label/Cap remover machine 1000kg/h technical Parameter:
| 1 | Motor power | 30kw |
| 2 | Water pump power | 5.5kw |
| 3 | Rotational speed | 500rpm |
| 4 | The contact part with raw material is made of stainless steel | |
.
If you want to know more informations about PET washing line ,welcome to contact with us.
We also can do PP PE washing line and granualting machine, plastic pipe making machines etc.
Contact Person: Shadow Fan
Tel: 0086 139 1360 8802
Fax: 86-512-58288488
