Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h

China Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h supplier
Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h supplier Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h supplier Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h supplier Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h supplier

Large Image :  Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h

Product Details:

Place of Origin: JIANGSU,CHINA
Brand Name: STPLAS
Certification: CE
Model Number: STPLAS 05

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Contact us
Packaging Details: film package or Plywood packaging suit for shipment.
Delivery Time: 30-45days for plastic bags granulator
Supply Ability: 20 sets/month
Contact Now
Detailed Product Description
Capacity: 80-600kg/h Material: 304 Stainless Steel
Application: Film/fiber/bags Crush After Sales Service Provide: Engineer Available To Service Machinery Overseas



Plastic bags granulator used in pelletizing extruder 100-600kg/h





Features:



The granulator is a device for direct granulation of discarded thermoplastic bags/films with a wall thickness of less than 2 mm. It can be applied to soft PVC, high-low pressure polyethylene, polystyrene polypropylene and Its thermoplastic waste products or films are pelletized, and waste polystyrene products can also be pelletized.



After the waste is thrown into the machine pot, the material is quickly cut into pieces by the shearing action of the high-speed rotating blade and the fixed blade. The shredded material or sheet flows along the inner surface of the pot body under the centrifugal force of the rotary plate. At the same time, the material under the action of sizing up and down, from around to the direction of the center of the pot body, due to the friction between the material itself at high speed and friction with the pot wall and the blade generates a lot of friction heat, so that the material temperature rose rapidly to half In the plasticized state, they stick together into small pieces. Before the material is about to be agglomerated, the quantitative water that is prepared in advance is sprayed into the material. The cold water meets the hot material and quickly vaporizes, taking away the heat from the surface of the material. The surface is cooled rapidly to prevent agglomeration and then shredded into particles (aggregates of irregular sizes) by the breaking action between the rotating blade and the stationary blade. In the process of crushing, you can also add appropriate pigments for coloring



The pellets produced by this machine can be directly used for extruders and injection machines. For products with strict requirements, they can also be extruded and granulated before being plasticized and used after granulation.



Main technical parameter:



Model ST-100 ST-200 ST-300 ST-400 ST500 ST600
Motor power(kw) 45 55 75 90 110 160
Cubage(L) 100 200 300 400 500 600
Rotating knives(Pc) 2 2 2 2 4 4
Fixed Knives (Pc) 4 4 6 6 8 8
Speed of rotating(rpm) 880 850 820 800 780 750
Capacity(kg/h) 80-150 150-180 200-250 270-350 400-500 500-600



More Photos of plastic film agglomerator:



Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h



After granulator, the final material sample:



Stainless Steel Plastic Granules Manufacturing Machine Granulator 100-600kg/h



If you want to know more informations ,welcome to contact with us.
