Silent Plastic Bottle Shredder Machine / PET Water Bottle Recycling Machine

Silent Plastic Bottle Shredder Machine / PET Water Bottle Recycling Machine

Plastic Bottle Shredder Machine Introduction

This series plastic recycling machine will be used to recycle pet bottle, water bottle, Sprite bottle, cola bottle, juice bottle, pet sheet, pet packing container and so on.

Pet recycling machine include label remover machine, grinder crusher machine, sorting equipment, hot washing tank, friction washing machine, float washing tank, hot air dryer system, zig zag label separator, air silo etc.

After washing recycling, dirty pet material will remover label, oil, glue, sand etc.

new flakes can make 2-d or 3-d pet fiber, filament yarn, pet strap, pet sheet, pet film etc.

we supply 500-5000 kg/h or customized the big capacity for customer

High speed friction washer to cleaning the flakes by rpm high speed friction, process with water, Floating washer tank to remove the dirty, Hot washer chamber add some chemicals (e.g. suda) to remove the oil/grease, etc… Dewatering machine to remove the wate, rotation speed reach rpm.

Final products has good quality. When process PET bottle, final products humidity below 1%, impurities 100 rpm, PVC label content 100 ppm, The whole line capacity between 300kg/h-3000kg/hour

Parts which contact material use SUS304 stainless steel, thickness more than 3mm, ensure long service lift time

The whole production line with CE certification, ISO900 1 certification

Plastic Bottle Shredder Machine Feature

1. Easy to operate, low electricity consumption & durable and Low noise.
2. Uses high quality steel material especially for making cutter of the crushers, .
3. The blades can be grinded for many times and can be used repeatedly,

We can design different recycling line for you according to your request:

1. parallel bale opener can process the PET bottle packages from 100~600kg, more safety
2. roller sorting machine: separate the impurities out from the PET bottles, such as metal, sand, etc.
3. label removing system: use the gearshape blades to peel off the labels from the bottles body, removingratio>98%
4. sorting table: detect metal automatically for crusher protection, and separate the PVC bottles out manually after a UV-detect device.
5. Crusher: the blades are made of SKD-II, wearable and long life.
6. Screw feeder: spiral convey and wash the PET flakes by the friction force in the special structure.
7. friction washing machine: three friction force here for washing during the high speed rotating: rotor and flakes,steel sieve with flakes, flakes and flakes.

Plastic Bottle Shredder Machine Components

Plastic crusher

Function: size reduction of material into flakes

Washing tank

Function: cleaning flakes; density separation dirt from flakes

Hot Washing Tank

Function: with hot & chemical water washing to remove glue and greasy dirt from flakes

Dewatering Machine

Function: removal of moisture from flakes by high speed blade.
