Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade

Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade

    • Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade
    • Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade
    • Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade
    • Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade
  • Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade

    Product Details:

    Place of Origin: CHINA
    Brand Name: STPLAS
    Certification: CE
    Model Number: STPLAS 03

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Contact Us
    Packaging Details: film packing suit for shipping
    Delivery Time: 30-80days
    Payment Terms: T/T, L/C
    Supply Ability: 10 lines/year
    Contact Now
    Detailed Product Description
    Material: 304SS With Water Crusher Blade: SKD-II Or D2
    Certificate: CE Raw Material: Waste Film, Bags
    Capacity: 300-2000kg/h Hummity: Less Than 1%



    300-2000kg/h Line HDPE recycling process for bottles , barrels , bucket , pipes



    HDPE recycling is a very important part in plastic recycling area. The complete production line is developed through the introduction and absorption of advanced concepts and technologies of the same industry in the world, combined with the current development needs and the characteristics of the secondary application of waste plastics. It can meet the environmental protection requirements for the recycling of waste plastics at home and abroad.







    This HDPE recycling washing plant is suit for below material recycle:



    1. HDPE hard flakes,
    2. milk bottle,
    3. Oil tank chemical barrel,
    4. Blue bucket,
    5. Drinking water barrel,
    6. PE pipes,
    7. plastic baskets,
    8. card board etc. hard plastic

    Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade

    Features of HDPE bottle recycling line:



    1. Final products has good quality, final products humidity below 1%
    2. crusher knife material is SKD11, durable;
    3. screw conveyor, rinse tank made of stainless steel 304;
    4. The dewatering part adopts wringing machine, which has large output, high efficiency, no need of hot air drying, and greatly reduces the electricity consumption.



    One whole line of 500kg/h HDPE recycling line as below items:



    No Name Power
    1 Belt conveyor 1.5kw
    2 Crusher 37kw
    3 Double screw conveyor 1.5kw *2
    4 High speed friction washer machine 11kw
    5 Screw conveyor 2kw
    6 Floating washer 1.5kw+1.5kw+1.5kw
    7 Drainage screw 1.5kw
    8 Screw conveyor 1.5kw
    9 Vertical dewatering machine 5.5kw
    10 Drying system 36kw + 7.5kw
    11 Zig zag air classify system 11kw +7.5kw





    HDPE bottle recycle washing equipment main technical parameter:



      Model ST-300 ST-500 ST-1000 ST-2000
    1 Capacity (kg/h) 300 500 1000 2000
    2 Water consumption (t/h) 1-2 3-4 7-8 10-15
    3 power consumption (kw/h) 130-160 210-260 300-350 400-480
    4 Staffs (person) 2-3 2-3 3-5 6-8
    5 Plant area (m) 30*4*5 40*4*5 46*6*5 60*6*5





    After washing, HDPE flakes will go to extruder:



    Main technical Parameter of HDPE pelletizing line :



    Model

    Screw diameter

    (mm)

    L/D

    sub- screw diameter

    (mm)

    L/D

    Capacity

    (kg/h)

    SJ80 80 30-34 80 10:1 150-200
    SJ100 100 30-34 100 10:1 200-250
    SJ120 120 30-34 120 10:1 300-350
    SJ130 130 30-34 130 10:1 350-400
    SJ150 150 30-34 150 10:1 400-500
    SJ180 180 30-36 180 10:1 500-700
    SJ200 200 30-36 200 10:1 800-1000

























    Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade

    Line HDPE Plastic Washing Recycling Machine With SKD11 Durable Blade

    Turnkey project service:



    1. we will provide all the machines for the complete production according to customer's requirements.

    2. we will provide complete service for factory layout and other information to help customer to build the factory.

    3. we will provide good service for machine installation and training, until the customers can run the machines and make stably production.

    4. Except one year quality guarantee, we will provide after-sell service for all the life.

    5. for long-term cooperation, we always provide good quality, good price and good service to customer.
